1.Features

 Up to 32 cameras realtime preview
 H.264 dual-stream video compression
 4 D1+28CH CIF or 32CH CIF realtime recording @CH
 16ch sync realtime playback
 HDMI output up to 1080p, 1 TV, 1 VGA,1 SPOT
 Support 4 SATA HDD up to 8TB
 Multiple network monitoring: Web viewer, CMS and Mobile phone
2.Technical Specifications


KD32
System
Operating System	Embedded LINUX
Video
Input	32 channel, BNC
Standard	NTSC(525Line,60f/s),PAL(625Line,50f/s)
Audio
Input	16 channel, RCA
Output	1 channel, RCA
Display
Interface	1 HDMI, 1 VGA, 1 BNC, 1 SPOT
Resllution	800*600;1024*768;1280*1024;1440*900;1920*1080
Display Split	1/4/9/16/32
Recording
Video/Audio Compression	H.264 / G.711
Resolution	D1(704×576/704×480)/CIF(352×288/352×240)
Record Rate	4CH D1+28CH CIF or 32CH CIF
Record Mode	Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval	15～60min (default:60min);Pre-record:5sec;Alarm-record: 30～300sec
Video Detection & Alarm
Trigger Events	Recording，Alarm，Video Push，Email, Buzzer
Video Detection	Motion Detection, Video Loss, HDD Loss
Alarm Input	16 channel
Relay Output	2 channel
Playback & Backup
Sync Playback	1/4/9/16
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second)
Playback Functions	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode	USB Device / Internal SATA burner/ Network
Network
Ethemet	RJ-45 port (10/100M)
Network Functions	HTTP, IPv4/IPv6, TCP/IP, UPNP, DHCP, DNS, PPPOE, DDNS
Max.User Access	3 users
Mobile Phone	IPhone, IPad, Android
Storage
Internal HDD	4 SATA ports (4HDDs or 2HDDs+1CD/DVD-RW), up to 8TB
Auxiliary Interface
USB Interface	2 ports (1 Rear), USB2.0
RS232	Yes
RS485	1 port, For PTZ control
General
Power Supply	DC12V/6A
Power Consumption	45W(without HDD)
Working Environment	-10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W*D*H)	440*455*96 (mm)
Weight	4.5-5.0kg(without HDD)

Sistema:

•   Sistema Operativo Linux RTOS, Buena transmicion de datos en la red, alta estabilidad

•   Interfaz GUI, seleccion multiligue

•   Con Deteccion de movimientos

•   Grabacion Manual, Grabacion programada

• Multi-Plex: Preview, Playback, backup, transmicion de red simultanea.

• Nota:
  • Facil de Instalar
  • Incluye Mouse
  • Incluye fuente de Poder
  • Incluye control Remoto
  • Incluye Manual de Uso en Ingles.

• Si desea Factura Agregar el 16% de IVA.
• No Incluye Envio
• Aceptamos Depositos a Cuenta de Banco, Tarjetas de Credito y Debito.
