Especificaciones:

• Model NO			3204
  Feature	Operation System		Linux
  Video	Video System		NTSC/PAL Switch Selectable
  	Video Input		BNC*4 (1.0Vp-p 75Ω)
  	Video Output		1 CH BNC(1.0Vp-p 75Ω); 1 CH HD VGA Output
  	Spot		N/A
  	Loop Out		N/A
  	VGA Output		800*600;1024*768;1280*1024;1440*900
  Audio	Input		1 CH RCA
  	Output		1 CH RCA
  	Talk Back		YES
  Control	Mouse		USB2.0
  	IR Controller		YES
  Storage	Build In Interface		SATA HDD 1ea (Up to 2TB)
  Display	Division		1,4
  	Zoom		Preview and Playback Zoom Support
  Recording	Compression		H.264 Main Profile
  	Recording Mode		Manual/Schedule/Motion Detection/Sensor
  	Record Frame Rate (PAL/NTSC)		4CH D1@6fps/CH, 4CH CIF@30fps/CH
  	Quality		Best,Fine,Norm,Bit-rate settings(16kbps-2Mbps)
  	Motion Detection		High, Higher, Middle, Low
  	Water Mark		YES
  Playback	Playback Frame Rate (PAL/NTSC)		4CH D1@6fps/CH, 4CH CIF@30fps/CH
  	Multi Channel Playback		1,4
  	Speed		Normal, Slow & Fast(1/5,1/4,1/3,1/2,1,2﹡,3﹡,4﹡,5﹡)
  	Search Method		Time, Even, Channels and Calendar
  Communication	Remote Software		Remote Client, IE Brower, Mobile, CMS, Firefox, Google Ghrome
  	Remote Operation		Remote view, Remote playback, Remote setup
  	Network Service		TCP/IP, UDP, HTTP,DDNS, SMTP(SSL), LAN, DHCP, PPPOE
  	WAN RJ45		10/100 Mbit/s
  	Mobile		Symbian, Iphone, Blackberry, Andrews
  	GUI Interface		Supported GUI 16 Bit True Color
  	PTZ Protocol		1*RS485, Support 18 Kinds of Protocol
  Backup	Internal		N/A
  	External		USB2.0
  	Network		YES
  	File		H.264 Compression/AVI
  General	Alarm In/Out		N/A
  	RS-485		1
  	RS-232		N/A
  	Operation Temperature		10°～50°
  	Working Humidity		10%～90%
  	Power Consumption		DC12V, 2A, 10-12W(Exclude HDD)



Sistema:

•   Sistema Operativo Linux RTOS, Buena transmicion de datos en la red, alta estabilidad

•   Interfaz GUI, seleccion multiligue

•   Con Deteccion de movimientos

•   Grabacion Manual, Grabacion programada

• Multi-Plex: Preview, Playback, backup, transmicion de red simultanea.

• Nota:
  • Facil de Instalar
  • No Incluye Mouse
  • Incluye fuente de Poder
  • Incluye control Remoto
  • Incluye Manual de Uso en Ingles.

• Si desea Factura Agregar el 16% de IVA.
• No Incluye Envio
• Aceptamos Depositos a Cuenta de Banco, Tarjetas de Credito y Debito.
